Specifications Referrence of FSSANXIN Best-seller (Take SXH-924 Model as an example)
Model	SXH-924 350(400)*800mm
Control System	C56 Model 8 inch Computer
Running Speed	750-1200rpm
Power Supply	380V 3 Phase
Main Shaft Motor	Servo Motor
X&Y Driving Motor	Servo Motor
Machine Head	SHUANGXIN High Speed Head
X&Y Driving Belt	Imported High Strength Belt
Body Structure	Integrative Machine Body
X&Y Driving Guide	Linear Guide
Jump Stitch Controler	Stepping Motor
Up Thread Catcher (UTC)	SHUANGXIN UTC Device

Model Referrence of FSSANXIN Best-seller
Model	Needle No	Head No	Headdistance	Max Area of X	Max Area of Y	Machine size
SXH一904	9(6/12)	4	400	800	800	3700	2100	1700
SXH一908	9(6/12)	8	400	800	800	5300	2100	1700
SXH一915	9(6/12)	15	400	800	800	8100	2100	1800
SXH一918	9(6/12)	18	350	700	800	8300	2100	1900
SXH一920	9(6/12)	20	350	700	800	9000	2100	1900
SXH一924	9(6)	24	350	700	800	10400	2100	1900
SXH一928	9(6)	28	330	660	900	11200	2300	1900
SXH一930	9(6)	30	300	600	900	10800	2300	1900
SXH一636	6(4)	36	300	600	900	12600	2300	1900

We can accept different models according to requirements from customer


FSSANXIN independent developed single cam high speed flat head,extremely low maintenance rate,more durable service life.

FSSANXIN independent developed upper thread catcher device(UTC)，avoid thread dropping，get excellent trimming performance.

FSSANXIN firstly design flat needle plate with a hole for clean and maintenance trimming system,easy and convenient.

Head and hook box adapt the lubrication system of 6000rpm industrial sewing machine, it gives stable oiling and never have grease spots on fabric.

Economic micro motor trimming system,less noise and stable with less maintenance cost.


FSSANXIN independent developed thread guiding tension box with linoleum. It can oiling thread and make thread move smoothly. It also helps to get beautiful stitch and reduces thread breakage rate.

Snap-in type thread stand, it makes easy to change thread for difference production and save time.

Jump stitch use step motor, it helps to reach highest speed with lowest noise.

Light but strong aluminum pantogragh have durable}ife and less deformation.It guarantees beautiful stitch.

X&Y shaft use servo motor for driving, pantograph easily moves accurately.


We reserve the rights to update the technical specifications without notice in advance.All specifications should according to the contract which sign with customer.	We reserve the rights to update the technical specifications without notice in advance.All specifications should according to the contract which sign with customer.


We reserve the rights to update the technical specifications without notice in advance.All specifications should according to the contract which sign with customer.	We reserve the rights to update the technical specifications without notice in advance.All specifications should according to the contract which sign with customer.


We reserve the rights to update the technical specifications without notice in advance.All specifications should according to the contract which sign with customer.
